INTELLIGENT 001 smart lock TTLock
€135.00
External electric bolt lock, code panel - backlit touch keyboard, contactless card reader, Bluetooth, WiFi, biometric reader, IP66, TTLock app, two physical keys, molded battery, USB charging
online consultation:
For indoor and outdoor use.
For remote control and monitoring, the INTELLIGENT 001 TTLock electric lock must be connected to a WiFi router via the ACA-20C9 WiFi gateway, which is not included in the package and must be purchased separately.
Functions:
- TTLock app & Web console control system;
- Remote control via the ACA-20C9 WiFi gateway, which is not included in the package and must be purchased separately;
- e-Key Bluetooth in a smartphone, via the TTLock mobile app. Available for guests' and users' smartphones;
- Fingerprint lock opening;
- Contactless cards and key fobs.
- Remote programming of new contactless cards or key fobs by the user (in accordance with clause 2);
- Powered by a rechargeable battery;
- Electric lock design - retractable bolt;
- Can be installed on doors 35-65 mm thick;
- Protection against locking the electric lock bolt on an open door.
The ACA-20C9 WiFi gateway is sold separately.
INTELLIGENT 001 TTLock electric lock, settings and control:
|
TTLock app apartments, shops, offices, guest houses ... |
After registering in the TTLock mobile application, the user has access to all functions of the
TTLock Web Console: https://lock.ttlock.com/
|
<<< INTELLIGENT 001 TTLock installation and operation manual.
Technical specifications:
| Power type | Alkaline batteries (4 x AA 1.5V) |
| Max number of users | Cards - 100, Fingerprint - 100, PIN Codes - 100, E-Key - unlimited |
| Designed for doors | left/right |
| Housing material | Zinc alloy |
| Duration of the release pulse | 5-90 sec. |
| Bluetooth | Yes |
| Max. radiation power (Bluetooth) | <10mW |
| Operating frequency (Bluetooth) | 2.4GHz |
| Scrambler | Yes, touchscreen |
| Permissible relative humidity | 0-95% |
| Operating temperature range | -20ºC ~ +60ºC |
| Recommended installation location | internal and external |
| Protection factor | IP66 |
| Net weight | 1300 g |
| Logistics data | - |
| Packaging dimensions (H x W x D) | 90 x 255 x 210 mm |
| Gross weight | 1500 g |
| Packaging type | Cardboard |
